Introduction to version control with Git and GitHub

Max Horn

2025-09-16

What and why is version control?

  • “Version control” is about managing and tracking different versions of files
  • E.g. program code, \(\mathrm{\TeX}\) sources, config files
  • Great for collaborations, but also helpful for using it on your own

Tracking versions versus changes

  • Version control tracks different version of files

  • Equivalently: it tracks changes made to files

  • In version control lingo, a “version” is also called commit

  • From the verb “commit”, which can mean

    to consign or record for preservation;
    to commit something to memory

  • Let’s visualize this

Tracking changes

  • Start with a base version of a document
  • Track changes to content
  • May also track who made the change, when and why?
  • Viewpoint of tracking changes opens up new possibilities

Collaboration

If unrelated changes are made…

… we may be able to merge them into one document

Tools

  • Version control can be done completely manually
  • But this is about automated version control
  • with a VCS (version control system), such as Git
  • A VCS provides tooling to record and track commits and interact with them
  • Git is the de facto industry standard (for now)

GitHub ≠ Git

  • Some people think GitHub and Git are synonymous
  • This is wrong: GitHub is “just” a website hosting data recorded by git
  • There are many others, e.g. GitLab, Codeberg, SourceForge, etc.
  • but GitHub is what OSCAR uses (for now)
  • These websites often offer much more (e.g. issue tracker, website hosting, …)

Different ways of working on a repository

  • A repository is a storage area where Git stores the full history of commits of a project
  • If it is on GitHub, you can edit with just your web browser
  • For more complex work you should do it locally on your compute
  • Either via terminal commands (most powerful and flexible)
  • Or via a graphical interface, e.g. VS Code (easier to learn?)

Exercise: Edit Summer School website

Goal: Add your GitHub username to the participants list via the web browser

  1. go to the “participants” list on the Summer School website

  2. locate the “Edit this page” link

  3. use it and make the change (you need to insert 1 line)

  4. create the pull request

Preparing for Git and GitHub

  • Tell git who you are, via terminal:

    git config --global user.name "John Doe"
git config --global user.email johndoe@example.com

  • Of course use your own name and email address instead 😬

  • Privacy warning: This data will be associated with your subsequent Git activity

  • Set your real name on GitHub: https://github.com/settings

  • For terminal users: install gh via https://cli.github.com

  • If you use VS Code, install “GitHub Pull Requests” extension

What are clones and forks ???

  • A clone of a repository is a copy of all data and history

  • Original and copy may be on the same computer, or one or both on a remote computer

  • If both are on a remote computer, we call the copy a fork

  • All copies of the repo (including original) can now undergo history changes

  • Now the FUN starts: histories can diverge

    Let’s visualize this

Cloning and forking

  1. Fork the repository https://github.com/oscar-system/SummerSchool2025_Playground in the GitHub web interface.

  2. Clone your fork to your computer. (Hint: git clone)

  3. In your local clone, in the solutions directory: create a subdir with your name, in it add a file with solutions to some exercises.

  4. Commit the new file and push to your fork. (Hint: git add, git commit, git push)

Pulling and pull requests

  • You just pushed data from your local repository to a remote one
  • The opposite operation is pull (pull = fetch + merge)
  • One can also push and pull between forks of a repository
  • A pull request is … a request for someone to pull your changes 🤓
  • Exercise: Go to your fork of the repository on the GitHub website. From there, create a pull request to merge the additions into the original repository.

Reporting issues

  • GitHub manages not just git repositories, but also has an issue tracker
  • Exercise:

Using branches

  • We’d like to be good citizens and not just complain but actually fix the obviously wrong bikeshed color.
  • Best practice: use branches
  • A branch is just a “label” or “pointer” referencing a specific commit
  • Helps you manage diverging history

Managing branches

  • In git there is usually an active branch

  • Making commits updates the active branch

  • Create a new branch using git branch NEWBRANCH, list branches using git branch

  • Switch between branches using git switch or git checkout

  • Merge diverging history with git merge

    Let’s visualize this

Exercise: change the bikeshed color

  1. git pull our exercise repository
  2. Create a new branch
  3. In it, edit README.md to have the correct color; commit your changes
  4. Push this to your fork, open a pull request as before

Dealing with merge conflicts

  • Unfortunately, someone else made a conflicting change: they replace the bikeshed color by another color – unfortunately still the wrong one
  • This caused a merge conflict
  • You need to deal with this: in your local clone, switch to the main branch, and pull the latest version.
  • Switch back to your work branch, and git merge the master branch
  • Resolve the merge conflicts, then commit and push
  • Verify your pull request was updated

Advanced: gh command line tool

  • Install the gh tool from https://cli.github.com
  • Some things it does for you:
    • takes care of passwords etc.: gh auth login once
    • submit pull requests with ease
    • create, clone, fork, and view repositories
    • browse and manage issues and pull requests
    • … and much more

The End



Thank you for your attention!
